R45 高速全自动丝网印刷生产线 -

产品展示

您现在的位置： >> 网站首页 >> R45 高速全自动丝网印刷生产线

案例名称：R45 高速全自动丝网印刷生产线
更新时间：2020.06.04
出品单位：

更多产品图片：

详细介绍：

产品简介Product Profile

专为圆形承印物而设计，结构简单合理调试方便快捷、运行稳定可靠。

整机集成同步自动上料、自动升降印刷及紫外线固化等多种功能，大大提高了印刷效率

印刷速度最快可达3000/hr。

通过触摸屏显示屏操作轻松实现人机对话，使操作更加得心应手。

具备圆瓶预先对位功能，使印刷过程更高效更精准

通过电子传感器实现“无件不印刷”、气压过低报警等自动监测功能。

全机电气元件及控制系统均进口自德国日本，确保了稳定得印刷品质。

可依据客户对自身产品的特殊要求，专门设计并量身定做设备。

Designed for circular substrate, the structure is simple, reasonable and convenient to debug, stable and reliable operation.

The whole machine integrates various functions such as synchronous automatic feeding, automatic lifting printing and UV curing, which greatly improves the printing efficiency

As fast as 3000/ hr. printing

Through touch screen operation easy to achieve man-machine dialogue, so that the operation more handy.

Has the round bottle pre-position function, makes the printing process more efficient and accurate

Through the electronic sensor to achieve "no printing ", too low air pressure alarm and other automatic monitoring functions.

All electrical components and control systems are imported from Germany and Japan to ensure stable printing quality.

According to the customer's special requirements for their own products, specially designed and customized equipment.

性能特点Characteristics

自动可调速防磨入料输送带及入料检测装置

美国高效UV灯固化系统

2米长成品检验输送带

独立PLC程控器及易用触摸屏操作控制系统

采用世界知名品牌电元器件，确保机器的持久稳定和耐用

Automatic adjustable speed and anti-wear feeding conveyor belt and feeding detection device

High Efficiency UV Lamp Curing System

2m long inspection conveyor belt

Independent PLC program controller and touch screen operating control system

Adopt world famous brand electric components to ensure the lasting stability and durability of the machine

技术参数（Specifications)

最大印刷面积（Max Printing Area) 320×250mm

最小产品直径（Min Cylindrical container Diameter) Φ20mm

最小产品高度（Min Container Height) 50mm

最大瓶子宽度（Max Container Width) 120mm

电源电压（Power Voltage) 380V 50Hz

供气压力（Air pressure) 5-7kg/cm²
